TYCO KEYSTONE F611蝶阀现货
TYCO KEYSTONE F611蝶阀现货
产品特性：TYCO阀门代理商,KEYSTONE代理商,泰科F611蝶阀供应商,KEYSTONE F611蝶阀
产品简介：TYCO KEYSTONE F611 系列蝶阀 F611系列为通用型弹性阀座蝶阀，主要用于要求气泡级密封的工况上，结构简单、易维护。*尺寸：DN40-900mm*温度：-40--120度*压力：1.6MPA最大*连接标准：DIN,ANSI
| 品牌 | TYCO | 型号 | F611 DN65 | 所在地 | 广东深圳龙岗区 |
深圳市德隆泰科技有限公司
详细介绍：
TYCO KEYSTONE F611/DEE2/DN65/AN蝶阀 正品现货特价供应，欢迎洽谈
F611/F612系列为通用型弹性阀座蝶阀，主要用于要求气泡级密封的工况上，结构简单、易维护。
*KEYSTONE 标准顶法兰
*一片式阀体
*加长阀颈，适用于管路保温
*阀座可以更换
*厚阀板设计，主要用于开关
*连接方式：对夹、支耳
*尺寸：DN40-900mm
*温度：-40--120度
*压力：1.6MPA最大
*连接标准：DIN,ANSI
*阀体：铸铁，球铁，碳钢
*阀板：球铁，铝青铜，不锈钢
*阀杆：不锈钢
*阀座：EPDM，NBR
蝶阀
Literature (pdf)
泰科流体控制旗下相关品牌
Keystone Valves
Neotecha
Sapag
Winn
F611/F612系列为通用型弹性阀座蝶阀，主要用于要求气泡级密封的工况上，结构简单、易维护。
*KEYSTONE 标准顶法兰
*一片式阀体
*加长阀颈，适用于管路保温
*阀座可以更换
*厚阀板设计，主要用于开关
*连接方式：对夹、支耳
*尺寸：DN40-900mm
*温度：-40--120度
*压力：1.6MPA最大
*连接标准：DIN,ANSI
*阀体：铸铁，球铁，碳钢
*阀板：球铁，铝青铜，不锈钢
*阀杆：不锈钢
*阀座：EPDM，NBR
蝶阀
泰科公司生产的蝶阀根据工况可分为以下三类：船舶、水处理、流程工业等行业，范围包括用衬胶阀座型和高性能型。化工或腐蚀性介质用全包覆产品；制药、食品饮料、日用化工行业用特殊设计的卫生级产品。
-
对夹、半支耳、支耳和法兰等连接方式
-
可更换和硫化阀座
-
多种橡胶阀座可选
-
火灾安全和非火灾安全型
-
尺寸范围：DN6至DN2750
-
压力等级：ANSI Class 150至300
-
温度范围：-196至399摄氏度
